| Type |
ROBDC120K-E |
| Rated Power |
120kW |
| Weight |
About 240kg |
| Single-gun Maximumoutput Current |
250A |
| Design Standard |
IEC 61851-1,EN 61851-23 |
| Input Voltage / Frequency |
380VAC士20%/50Hz士10% |
| Number of Guns |
Double guns |
| Length of Charging Gun Line |
5 meters |
| Output Voltage |
DC200~1000V |
| Noise |
≤60dB |
| IP Level |
IP55 |
| Network Method |
Ethernet、4G full Netcom |
| Man-machine Interface |
7-inch touch display screen+LED |
| Cloud Platform |
Support OCPP1.6 |
| Starting Mode |
Brush lC card, WeChat scan code, VlN, Password |
| Charging Mode |
Automatic full charge, Time, Quantity and Amount |
| Protection Function |
Short circuit, overcurrent, overtemperature, leakage, undervoltage, etc |
| Operation Temperature |
-20℃~+50℃ |
| Dimensions |
620*700*1700mm(W*D*H) |
