| Type |
ROBAC22K-E |
| Rated Power |
22kW |
| Input Voltage Range |
AC380V±20% |
| Output Current |
3*32A |
| Output Voltage |
AC380V±20% |
| Number of Guns |
Single-gun |
| Design Standard |
IEC 61851 、IEC 62196-2 |
| Input Frequency |
50±1Hz |
| Man-machine Interface |
Man-machine Interface |
| Network Method |
Ethernet, 4G, Bluetooth, WiFi |
| Charging Mode |
timing and other strategy charging |
| Cloud Platform |
Support OCPP1.6 |
| Starting Method |
Small program or Scan code or By WeChat |
| Protection Function |
Short circuit, overcurrent, over temperature, leakage,overvoltage，ETC |
| IP Level |
IP55 |
| Operation Temperature |
-20℃~~50℃ |
| Length of Charging Gun Line |
5 Meters（Standard Configuration） |
| Direction of Input Line |
Down and Down |
| Dimensions |
179*421*145mm(W*H*D) |
